three Insulation consumption( Kg/Km ): = ( D^2 - d^2 ) * 0.7854 * G * C * K2
“ D ”Indicate: insulation outer diameter
“ d ”Indicate: outer diameter of conductor
“ G ”Indicate: insulation specific gravity
“ K2 ”Represent: core wire stranding rate
“ C ”Indicate: number of insulated core wires
six Amount of winding:( Kg/Km ) = d^2 * 0.7854 * G * N * Z
“ d ”Indicate: conductor wire diameter
“ N ”Indicate: number of pieces
“ G ”Indicate: Specific gravity
“ Z ”Represent: stranding rate
seven Braiding amount:( Kg/Km ) = d^2 * 0.7854 * T * N * G / cos θ
θ = atan( 2 * 3.1416 * ( D + d * 2 )) * Mesh number / 25.4 / T
“ d ”Indicate: braided copper wire diameter
“ T ”Indicate: number of ingots
“ N ”Indicate: number of bars per ingot
“ G ”Indicate: specific gravity of conductor
Specific gravity of common materials:
copper -8.89 ; silver -10.50 ; aluminum -2.70 ; zinc -7.05 ; nickel -8.90 ; tin -7.30 ; steel -7.80 ; lead -11.40 ; Aluminum foil Mylar -1.80 ; paper -1.35 ; Myra -1.37 ; PVC-1.45 ; LDPE-0.92 ; HDPE-0.96 ; PEF (Foaming) -0.65 ; FRPE-1.7 ; Teflon ( FEP ) two point two ; Nylon-0.97 ; PP-0.97 ; PU-1.21 ; Cotton tape -0.55 ; PP Rope -0.55 ; Cotton yarn -0.48
▲ With your golden finger, you can add an egg to the small plait by clicking the advertisement
among :K Is the overlap rate or clearance rate; if it is overlap, it is 1-K ; If it is clearance, it is 1+K
"ρ" means: material specific gravity
